2025

F-PLAY 24

Name: F-PLAY 24
Brand: Mondraker
Availability: InStock

Brak ocen

Rower elektryczny młodzieżowy ogólnego zastosowania 24″ z aluminiową ramą, komponentami wyższej średniej klasy i hydraulicznymi hamulcami tarczowymi Shimano.

Typ roweru MTB

Kategoria General Youth

Waga 17,2 kg

Rama Aluminum

Zawieszenie Full, 120mm, 120mm

Widelec Aluminum

Amortyzator X-Fusion

Koła 24″, Aluminum

Napęd 1 × 12

Osprzęt Deore

Silnik MAHLE hub-drive

Bateria MAHLE 250Wh

Hamulce Shimano Hydraulic Disc

⚡ Oblicz zasięg roweru

Strona producenta

Specyfikacja

konstrukcja

Rama	F-Play 24 6061 Alloy Stealth evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, 1x drivetrain compatible, BB Standard: BSA, Threaded
Widelec	X-Fusion Slant RC 26, 120mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload, Travel: 120mm, Spring Type: Air
Amortyzator	X-Fusion 02PRO R, 165×42.5mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
Łożysko	Onoff ZS44/ZS56, 1-1/8″, 1.5″ head tube, ACB sealed bearings, top 42x30x7x45ºx45º, bottom 52x40x8x45ºx45º
Mostek	Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
Kierownica	MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Siodełko	SDG Fly JR
Sztyca	X-Fusion Manic LC internal, diameter 31.6mm, 1X Remote lever, 100mm, Type: Dropper
Pedały	SDG Slater JR
Chwyty	Onoff Beehive, 1lock-on, 135mm

Osprzęt

Przerzutka tylna	Shimano Deore M6100, SGS, Shadow+, 12s
Korba	Prowheel DMJ-CR094S-TT, Direct mount chainring, 150mm, Rings: 30T, steel
Manetki	Shimano Deore M6100, Rapid Fire Plus, 12s
Kaseta
Łańcuch	Shimano Deore M6100, 12s, Quick-link
Napinacz Łańcucha
Hamulce	Front: Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads, Rear: Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads, Type: Shimano Hydraulic Disc

Koła

Obręcze	MDK-HP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes
Szprychy	CN round stainless steel
Piasta przednia	DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts
Piasta tylnia	Mahle-Ebikemotion X-30, HG freehub
Opony	Front: Maxxis Minion DHF 24×2.4, Tubeless ready, 3C MAXX TERRA, EXO Protection, 60TPI, folding bead, Rear: Maxxis Minion DHR II 24×2.3, Tubeless ready, EXO Protection, 60TPI, folding bead
